Professional Beekeeping Honey Extractor Machine 70*70*91cm Dimension

Basic Information
Place of Origin: Chin honey extractor
Brand Name: supersweet honey extract
Certification: ISO
Model Number: sshe-02
Minimum Order Quantity: 10pcs
Packaging Details: carton
Delivery Time: 5-8 working days
Payment Terms: D/P, D/A, L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs
Detail Information
Size:: 67*63cm Product Name:: 6 Frame Honey Extractor
Frame: 2/3/4/6/8/12/20/24 Frame Dimension(L*W*H): 70*70*91cm
Material: 201/#202/#304 Stainless Steel After-sales Service Provided: Engineers Available To Service Machinery Overseas
Weight: 32 Kg Voltage: Manual
Power(W): Manual Brand: Super-Sweet
Applicationy: Filter Bee Honey Type: Honey Extractor
Honey Gate: Yes Legs: Yes
High Light:

electric honey extractor

,

manual honey extractor


Product Description



factory supply electric honey extractor motor



Electrical, 202 stainless steel,
With legs and plastic honey gate, speed control,
Frequency Converters,
three-phase, 220V, 550W

  • Feature:
  • 8 Frames Honey Extractor — Manually operated tangential extractor
  • This is a new 8 frame stainless steel extractor, ideal for the hobby scale beekeeper.
  • It has the outlet device at the bottom for controlling the the honey flow.
  • The size of extractor basket is: 67cm * 63cm. The max frame size is approx 26cm * 45m
  • Turning gear with bearings and metal gears, the drum is equipped with 3 legs.
  • Cage fits most frames (see technicals).
  • The bottom is conically shaped to drain the honey to the bung
  •
  • Product Advantages:
  • Tank, basket are made stainless steel, made from food-safe stainless-steel
  • Durable hand drive 1:3 with
  • Clear plexiglass top
  • 3 sturdy legs
  • 4 honeycomb stainless steel baskets suitable for the frames up to 26cm * 45cm
  •
  • Technical information:
  • Total height: ca. 114 cm
  • Drum height: 60 cm, with feet: 94 cm (stainless steel)
  • Drum diameter: 48 cm (inner 46 cm)
  • Frames sizes max.: 26cm * 45cm (at a minimum frame length of 19 cm)
  • Weight.: 32kg
  • Drive speed ratio: 3:1 (without free wheeling)
  • Outlet pipe diameter : 40mm
  • OEM/ODM: We experienced in this line.



Professional Beekeeping Honey Extractor Machine 70*70*91cm Dimension 0



Details honey extractor

2 frame ---24 frame

Item speciafication Packing
2 frame electronic

Manual, stainless steel,without legs or plastic,honey gate

SELF-REVERSAL

1pc/carton

50*50*87cm

13.5kg/carton

2 frame manual 202 stainles steel,with legs and plastic honey gate

1pc/carton

42*42*72cm

12kg/carton

3 frame manual 202stainless steel,with legs and plastic honey gate

1pc/carton

41*41*71cm

13kg/carton

3 frame electronic

stainless steel with longer legs and

plastic honey gate, speed control,

220V,140W seamless welding barrel

1pcs/carton

47*47*92cm

19kg

4 frame manual

202stainless steel,Assembled gear

with legs and plastic honey gate

Seamless welding

1pc/carton

52*52*78cm

21kg/carton

4 frame electronic

202stainless steel,With legs and plastic honey gate,speed control,

single-phase, 220V,140W

1pc/carton

53*53*91cm

6 frame manual



stainless steel,Assembled gear with legs, plastic honey gate

1pc/carton

73*73*83cm

32kg/carton

6 frame electronic

Electric, stainless steel,With legs and plastic honey gate,speed control,

single-phase, 220V,250W

1pcs/carton

75*75*107cm

34kg/carton

8 frame manual

stainless steel Assembled gear

with legs, plastic honey gate

1 pcs/carton

72*72*85cm

35kg/carton

8 frame electronic

stainless steel,With legs and plastic

honey gate,speed control,

Frequency Converters,three-phase, 220V,550W

1 pcs/carton

75*75*107cm

39.5kg/carton

12frame electronic

stainless steel,With legs and plastic

honey gate,speed control,

Frequency Converters,three-phase, 220V,550W

1pcs/carton

81*81*107cm

55.4kg/carton

24frame electronic

stainless steel,With legs and plastic

honey gate,speed control,

Frequency Converters,

three-phase, 220V,

550W

1pcs/carton

104*104*114c

m

80kg/carton
